Asus Zenfone 3 Max ZC520TL
Gallery
Specifications are collected from publicly available sources and may not be 100% accurate. We do not guarantee the completeness or correctness of the information presented.
Full Specifications
Launch
| Announced | 2016, July. Released 2016, August |
| Status | Discontinued |
Platform
| OS | Android 6.0.1 (Marshmallow), upgradable to 7.0 (Nougat), ZenUI 3 |
| Chipset | Mediatek MT6737M (28 nm) |
| CPU | Quad-core 1.25 GHz Cortex-A53 |
| GPU | Mali-T720MP2 |
Body
| Dimensions | 149.5 x 73.7 x 8.6 mm (5.89 x 2.90 x 0.34 in) |
| Weight | 148 g (5.22 oz) |
| SIM | Nano-SIM + Micro-SIM |
Display
| Type | IPS LCD |
| Size | 5.2 inches, 74.5 cm2 (~67.7% screen-to-body ratio) |
| Diagonal | 5.2 inches |
| Resolution | 720 x 1280 pixels, 16:9 ratio (~282 ppi density) |
| Screen Resolution (px) | 720x1280 |
| Pixel Density | 282 ppi |
Memory
| Card Slot | microSDHC (uses shared SIM slot) |
| Internal | 16GB 2GB RAM, 32GB 3GB RAM |
| RAM | 2 / 3 GB |
| Storage | 16 GB / 32 GB |
Network
| 2G Bands | Supported |
| 3G Bands | Supported |
| 4G Bands | Supported |
| 5G Bands | Not supported |
Main Camera
| Camera Module(s) | 13 MP, f/2.2, AF |
| Features | LED flash, panorama, HDR |
| Video | 1080p@30fps |
Front Camera
| Camera Module(s) | 5 MP, f/2.0 |
Connectivity & Features
| WLAN / Wi-Fi | Wi-Fi 802.11 b/g/n, Wi-Fi Direct |
| Bluetooth | 4.0, A2DP, EDR |
| GPS / Positioning | GPS, GLONASS, BDS |
| NFC | No |
| Sensors | Fingerprint (rear-mounted), accelerometer, proximity, compass |
Battery
| Type | Li-Po 4130 mAh, non-removable |
| Capacity | 4130 mAh |
| Charging | Reverse wired |
| Talk Time | Up to 20 h (3G) |
Miscellaneous
| Colors | Titanium Grey, Glacier Silver, Sand Gold |
| Models | X008D, X008DA, X008DC, X00KD |
| Price | About 230 EUR |
| Category | Smartphone |
