Asus Zenfone Max Pro (M1) ZB601KL/ZB602K
Gallery
Specifications are collected from publicly available sources and may not be 100% accurate. We do not guarantee the completeness or correctness of the information presented.
Full Specifications
Launch
| Announced | 2018, April. Released 2018, May |
| Status | Discontinued |
Platform
| OS | Android 8.1 (Oreo), upgradable to Android 9.0 (Pie) |
| Chipset | Qualcomm SDM636 Snapdragon 636 (14 nm) |
| CPU | Octa-core (4x1.8 GHz Kryo 260 Gold & 4x1.6 GHz Kryo 260 Silver) |
| GPU | Adreno 509 |
Body
| Dimensions | 159 x 76 x 8.5 mm (6.26 x 2.99 x 0.33 in) |
| Weight | 180 g (6.35 oz) |
| SIM | Nano-SIM + Nano-SIM |
Display
| Type | IPS LCD |
| Size | 5.99 inches, 92.1 cm2 (~76.2% screen-to-body ratio) |
| Diagonal | 5.99 inches |
| Resolution | 1080 x 2160 pixels, 18:9 ratio (~404 ppi density) |
| Screen Resolution (px) | 1080x2160 |
| Pixel Density | 404 ppi |
Memory
| Card Slot | microSDXC (dedicated slot) |
| Internal | 32GB 3GB RAM, 64GB 4GB RAM, 128GB 6GB RAM |
| RAM | 3 / 4 / 6 GB |
| Storage | 32 GB / 64 GB / 128 GB |
Network
| 2G Bands | Supported |
| 3G Bands | Supported |
| 4G Bands | Supported |
| 5G Bands | Not supported |
Main Camera
| Camera Module(s) | 13 MP, f/2.2, 25mm (wide), 1.12µm, PDAF Auxiliary lens or 16 MP, f/2.0, PDAF Auxiliary lens (6 GB RAM model only) |
| Features | LED flash, HDR, panorama |
| Video | 4K@30fps, 1080p@30/60fps |
Front Camera
| Camera Module(s) | 8 MP, f/2.2, 26mm (wide), 1.0µm 16 MP, f/2.2, 26mm (wide), 1/3.06", 1.0µm (6 GB RAM model only) |
| Features | LED flash |
| Video | 1080p@30fps |
Connectivity & Features
| WLAN / Wi-Fi | Wi-Fi 802.11 b/g/n, Wi-Fi Direct |
| Bluetooth | 5.0, A2DP, LE |
| GPS / Positioning | GPS, GLONASS, BDS |
| NFC | Yes (market dependent) |
| Sensors | Fingerprint (rear-mounted), accelerometer, proximity, compass, gyroscope, ambient light sensor |
Battery
| Type | Li-Po 5000 mAh, non-removable |
| Capacity | 5000 mAh |
| Charging | 10W wired |
| Talk Time | Up to 42 h (3G) |
Miscellaneous
| Colors | Meteor Silver, Deepsea Black |
| Models | X00TD, X00TDB, X00TDA, ZB601KL, ZB602K, ZB602KL, ASUS_X00TD, X00T, X00TDE |
| Price | About 160 EUR |
| Category | Smartphone |
