Samsung
Samsung Galaxy Z Fold5
Gallery
Specifications are collected from publicly available sources and may not be 100% accurate. We do not guarantee the completeness or correctness of the information presented.
Full Specifications
Launch
| Announced | 2023, July 26 |
| Status | Available. Released 2023, August 11 |
Platform
| OS | Android 13, up to 4 major Android upgrades, One UI 8.5 |
| Chipset | Qualcomm SM8550-AC Snapdragon 8 Gen 2 (4 nm) |
| CPU | Octa-core (1x3.36 GHz Cortex-X3 & 2x2.8 GHz Cortex-A715 & 2x2.8 GHz Cortex-A710 & 3x2.0 GHz Cortex-A510) |
| GPU | Adreno 740 |
Body
| Dimensions | Unfolded: 154.9 x 129.9 x 6.1 mmFolded: 154.9 x 67.1 x 13.4 mm |
| Weight | 253 g (8.92 oz) |
| SIM | · Nano-SIM + eSIM· Nano-SIM + Nano-SIM + eSIM (max 2 at a time) |
Display
| Type | Foldable Dynamic AMOLED 2X, 120Hz, HDR10+ |
| Size | 7.6 inches, 183.2 cm2 (~91.1% screen-to-body ratio) |
| Diagonal | 7.6 inches |
| Resolution | 1812 x 2176 pixels (~373 ppi density) |
| Screen Resolution (px) | 1812x2176 |
| Pixel Density | 373 ppi |
Memory
| Card Slot | No |
| Internal | 256GB 12GB RAM, 512GB 12GB RAM, 1TB 12GB RAM |
| RAM | 12 GB |
| Storage | 256 GB / 512 GB / 1 TB |
Network
| 2G Bands | Supported |
| 3G Bands | Supported |
| 4G Bands | Supported |
| 5G Bands | Supported |
Main Camera
| Camera Module(s) | 50 MP, f/1.8, 23mm (wide), 1/1.56", 1.0µm, dual pixel PDAF, OIS 10 MP, f/2.4, 66mm (telephoto), 1/3.94", 1.0µm, PDAF, OIS, 3x optical zoom 12 MP, f/2.2, 12mm, 123˚ (ultrawide), 1/3.06", 1.12µm |
| Features | LED flash, HDR, panorama |
| Video | 8K@30fps, 4K@60fps, 1080p@60/240fps (gyro-EIS), HDR10+ |
Front Camera
| Camera Module(s) | 4 MP, f/1.8, 26mm (wide), 1/3.0", 2.0µm, under display Cover camera: 10 MP, f/2.2, 24mm (wide), 1/3.0", 1.22µm |
| Features | HDR |
| Video | 4K@30/60fps, 1080p@30/60fps, gyro-EIS |
Connectivity & Features
| WLAN / Wi-Fi | Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, Wi-Fi Direct |
| Bluetooth | 5.3, A2DP, LE, aptX HD |
| GPS / Positioning | GPS, GLONASS, GALILEO, BDS |
| NFC | Yes |
| Sensors | Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometer |
Battery
| Type | Li-Po 4400 mAh |
| Capacity | 4400 mAh |
| Charging | 25W wired, 50% in 30 min 15W wireless 4.5W reverse wireless |
Miscellaneous
| Colors | Icy Blue, Phantom Black, Cream, Gray, Blue |
| Models | SM-F946B, SM-F946B/DS, SM-F946U, SM-F946U1, SM-F946N, SM-F946W, SM-F9460 |
| Price | € 677.56 / $ 454.57 / £ 472.70 / ₹ 129,999 |
| Category | Foldable |
