Xiaomi
Xiaomi 17 Pro Max
Gallery
Specifications are collected from publicly available sources and may not be 100% accurate. We do not guarantee the completeness or correctness of the information presented.
Full Specifications
Launch
| Announced | 2025, September 25 |
| Status | Available. Released 2025, September 25 |
Platform
| OS | Android 16, HyperOS 3 |
| Chipset | Qualcomm SM8850-AC Snapdragon 8 Elite Gen 5 (3 nm) |
| CPU | Octa-core (2x4.6 GHz Oryon V3 Phoenix L + 6x3.62 GHz Oryon V3 Phoenix M) |
| GPU | Adreno 840 |
Body
| Dimensions | 162.9 x 77.6 x 8 mm (6.41 x 3.06 x 0.31 in) |
| Weight | 219 g (7.72 oz) |
| SIM | Nano-SIM + Nano-SIM |
Display
| Type | LTPO AMOLED, 68B colors, 2160Hz PWM, 120Hz, Dolby Vision, HDR Vivid, HDR10+, 3500 nits (peak) |
| Size | 6.9 inches, 116.6 cm2 (~92.3% screen-to-body ratio) |
| Diagonal | 6.9 inches |
| Resolution | 1200 x 2608 pixels, 19.5:9 ratio (~416 ppi density) |
| Screen Resolution (px) | 1200x2608 |
| Pixel Density | 416 ppi |
| Protection | Xiaomi Dragon Crystal Glass 3 |
Memory
| Card Slot | No |
| Internal | 512GB 12GB RAM, 512GB 16GB RAM, 1TB 16GB RAM |
| RAM | 12 / 16 GB |
| Storage | 512 GB / 1 TB |
Network
| 2G Bands | Supported |
| 3G Bands | Supported |
| 4G Bands | Supported |
| 5G Bands | Supported |
Main Camera
| Camera Module(s) | 50 MP, f/1.7, 23mm (wide), 1/1.28", 1.22µm, dual pixel PDAF, OIS 50 MP, f/2.6, 115mm (periscope telephoto), 1/1.95", 0.8µm, PDAF (30cm - ∞), OIS, 5x optical zoom 50 MP, f/2.4, 17mm, 102˚ (ultrawide), 1/2.88", 0.61µm, PDAF |
| Features | Laser AF, color spectrum sensor, Leica lens, Dual-LED dual-tone flash, HDR, panorama |
| Video | 8K@30fps (HDR), 4K@30/60/120fps (HDR10+, 10-bit Dolby Vision HDR, 10-bit LOG), 1080p@30/60/120/240/960fps, 720p@1920fps, gyro-EIS |
Front Camera
| Camera Module(s) | 50 MP, f/2.2, 21mm (wide), 1/2.88", 0.61µm, PDAF |
| Features | HDR, panorama |
| Video | 4K@30/60fps, 1080p@30/60fps, HDR10+, gyro-EIS |
Connectivity & Features
| WLAN / Wi-Fi | Wi-Fi 802.11 a/b/g/n/ac/6e/7, dual-band, Wi-Fi Direct |
| Bluetooth | 5.4, A2DP, LE, aptX HD, aptX Adaptive, LHDC 5 |
| GPS / Positioning | GPS (L1+L5), BDS (B1I+B1c+B2a), GALILEO (E1+E5a), QZSS (L1+L5), NavIC (L5), GLONASS |
| NFC | Yes |
| Sensors | Fingerprint (under display, ultrasonic), accelerometer, proximity, gyro, compass, barometer |
Battery
| Type | Si/C Li-Ion 7500 mAh |
| Capacity | 7500 mAh |
| Charging | 100W wired, PD3.0, QC3+, 100W PPS 50W wireless 22.5W reverse wireless |
Miscellaneous
| Colors | Black, White, Purple, Green |
| Models | 2509FPN0BC |
| Price | About 720 EUR |
| Category | Smartphone |
